TOT-TOT-BLK
Totem Cam
Four individually loaded cams obtain the excellent grip in a much wider variety of placements.
Diagonal micro-teeth on the cam lobes' frictional surface provide an additional grip and do not affect the logarithmic shape, as deep straight cut teeth can.
Greater holding power in downward flaring cracks.
Loadable on just 2 lobes, to exploit shallow or flared cracks where one or two of the outer lobes cannot establish contact. To load just two lobes connect a biner to the point where the sling joins the cam (recommended for aid only in this configuration).
- Trigger wires connect directly to cam lobes
- Internal spring for minimum head width
- Very flexible body
- Less walking due to strong springs and excellent flexibility
- Good expansion range
- Light, strong, durable
Four individually loaded cams obtain the excellent grip in a much wider variety of placements.
Diagonal micro-teeth on the cam lobes' frictional surface provide an additional grip and do not affect the logarithmic shape, as deep straight cut teeth can.
Greater holding power in downward flaring cracks.
Loadable on just 2 lobes, to exploit shallow or flared cracks where one or two of the outer lobes cannot establish contact. To load just two lobes connect a biner to the point where the sling joins the cam (recommended for aid only in this configuration).
- Trigger wires connect directly to cam lobes
- Internal spring for minimum head width
- Very flexible body
- Less walking due to strong springs and excellent flexibility
- Good expansion range
- Light, strong, durable
Active Strength | Passive Strength | Range | Weight | Materials | Conformity | |
---|---|---|---|---|---|---|
0.5 - Black | Active Strength
6kN
|
Passive Strength
0kN
|
Range
11.7-18.9 mm
|
Weight
69g
|
Material
Aluminium Alloy
|
Conformity
EN12276:2013
|
0.65 - Blue | Active Strength
8kN
|
Passive Strength
0kN
|
Range
13.8-22.5 mm
|
Weight
75g
|
Material
Aluminium Alloy
|
Conformity
EN12276:2013
|
0.8 - Yellow | Active Strength
9kN
|
Passive Strength
0kN
|
Range
17-27.7 mm
|
Weight
83g
|
Material
Aluminium Alloy
|
Conformity
EN12276:2013
|
1 - Purple | Active Strength
10kN
|
Passive Strength
0kN
|
Range
20.9-34.2 mm
|
Weight
95g
|
Material
Aluminium Alloy
|
Conformity
EN12276:2013
|
1.25 - Green | Active Strength
13kN
|
Passive Strength
0kN
|
Range
25.7-42.3 mm
|
Weight
109g
|
Material
Aluminium Alloy
|
Conformity
EN12276:2013
|
1.5 - Red | Active Strength
13kN
|
Passive Strength
0kN
|
Range
31.6-52.2 mm
|
Weight
132g
|
Material
Aluminium Alloy
|
Conformity
EN12276:2013
|
1.8 - Orange | Active Strength
13kN
|
Passive Strength
0kN
|
Range
39.7-64.2 mm
|
Weight
144g
|
Material
Aluminium Alloy
|
Conformity
EN12276:2013
|
